Wx.Gauge控件可以在確定的以及不確定模式中使用。當完成任何操作所需的時間可以被相當精確地確定，測量儀進度條顯示已完成任務的百分比。然而如果在不確定模式，它只是表示該過程正在進行中。

wx.Gauge(parent, id, range, pos, size, style)

此類一些的重要的方法列于下表中 −

實例

self.gauge = wx.Gauge(pnl, range = 20, size = (250, 25), style = wx.GA_HORIZONTAL)

self.btn1 = wx.Button(pnl, label = "Start")
self.Bind(wx.EVT_BUTTON, self.OnStart, self.btn1)

def OnStart(self, e):
   while True:
      time.sleep(1);
      self.count = self.count + 1
      self.gauge.SetValue(self.count)

      if self.count >= 20:
         print "end"
         return

import wx
import time
class Mywin(wx.Frame):

   def __init__(self, parent, title):
      super(Mywin, self).__init__(parent, title = title,size = (300,200))
      self.InitUI()

   def InitUI(self):
      self.count = 0
      pnl = wx.Panel(self)
      vbox = wx.BoxSizer(wx.VERTICAL)

      hbox1 = wx.BoxSizer(wx.HORIZONTAL)
      hbox2 = wx.BoxSizer(wx.HORIZONTAL)

      self.gauge = wx.Gauge(pnl, range = 20, size = (250, 25), style =  wx.GA_HORIZONTAL)
      self.btn1 = wx.Button(pnl, label = "Start")
      self.Bind(wx.EVT_BUTTON, self.OnStart, self.btn1)

      hbox1.Add(self.gauge, proportion = 1, flag = wx.ALIGN_CENTRE)
      hbox2.Add(self.btn1, proportion = 1, flag = wx.RIGHT, border = 10)

      vbox.Add((0, 30))
      vbox.Add(hbox1, flag = wx.ALIGN_CENTRE)
      vbox.Add((0, 20))
      vbox.Add(hbox2, proportion = 1, flag = wx.ALIGN_CENTRE)
      pnl.SetSizer(vbox)

      self.SetSize((300, 200))
      self.Centre()
      self.Show(True)

   def OnStart(self, e):
      while True:
         time.sleep(1);
         self.count = self.count + 1
         self.gauge.SetValue(self.count)

         if self.count >= 20:
            print "end"
            return

ex = wx.App()
Mywin(None,'wx.Gauge - www.yiibai.com')
ex.MainLoop()
